Application
Designed to lift 200L meat buggies and dump meat products into various processing equipment, such as sausage filling machines, mixers, grinders, and more.
Features
Quality Build: Full body 304 stainless steel with optional sandblast surface.
Control: Upper and lower limit switches for travel control and a jog button system.
Customized Lifting Fork: The lifting fork can be customized to accommodate different container types, such as 300L buggies, drums, or insulated barrels.
Optional Features:
• Lateral flip
• Mobile chassis for portability or fixed to the main machine without expansion bolts.
• Install safety guardrails.
Specifications
| Model | Discharge Height (mm) | Max Lifting Weight (kg) | Lifting Speed (m/min) | Power (kW) |
|---|---|---|---|---|
| TSJ140 | 1400 | 250 | 5.2 | 1.5 |
| TSJ180 | 1800 | 250 | 5.2 | 1.5 |
| TSJ200 | 2000 | 250 | 5.2 | 1.5 |
| TSJL200 | 2000 | 250 | 6.7 | 1.5 |
| TSJL240 | 2400 | 250 | 6.7 | 1.5 |
| TSJL300 | 3000 | 250 | 6.7 | 1.5 |
| TSJL400 | 4000 | 250 | 6.7 | 1.5 |
